Wooden Hole locator

A “wooden hole locator” in woodworking usually refers to a type of drilling jig or guide designed to help woodworkers drill accurate and consistently placed holes. While the term “wooden” might imply the jig itself is made of wood, modern hole locators often combine wood, metal, and plastic components for durability and precision.

Given the context of “Malpha bit set (wooden case)” and “Malpha hinges” (which are concealed cabinet hinges requiring a 35mm hole), a “wooden hole locator” is very likely referring to a hinge drilling jig or a dowel jig, which are essential for accurate hole placement in furniture making.

Here’s a breakdown of common types of “wooden hole locators” or drilling guides:

1. Hinge Drilling Jigs (especially for “Malpha” / Concealed Hinges)

• Purpose: To precisely locate and drill the 35mm cup hole (for the hinge cup) and sometimes the pilot holes for the mounting screws for concealed cabinet hinges. This is crucial for cabinet doors to open and close correctly and align perfectly.
• Features:
  • 35mm Guide Bushing: A fixed or adjustable guide specifically for the 35mm Forstner bit (often called “Malpha bit”).
  • Adjustable Fence/Clamping Mechanism: To secure the jig to the workpiece (e.g., cabinet door) and ensure the correct setback distance from the edge.
  • Measurement Scales: Often has markings to set the distance from the edge and between multiple hinges.
  • Material: While some simple ones might be primarily wood, many are made from durable plastics, aluminum, or a combination for accuracy and longevity. However, the term “wooden hole locator” could refer to jigs designed for wooden pieces or those with some wooden elements.
