Coofix CF-HM001 PPR Pipe Welding Machine Kit

Coofix CF-HM001 PPR Pipe Welding Machine Kit (also known as a socket fusion welder or thermo-fusion machine) is designed for joining plastic pipes and fittings, including PPR, PB, PE, and PVDF. It is widely used by plumbers and HVAC technicians for domestic hot/cold water distribution systems and industrial piping installations.

Technical Specifications

• Model: CF-HM001

• Rated Power Input: 800W – 1500W (dual-element heating configuration depending on batch/variant)

• Voltage/Frequency: 220V – 240V ~ 50/60Hz

• Working Temperature Range: 0°C to 300°C (adjustable thermostat)

• Working Range: $\varnothing$20mm to $\varnothing$63mm

• Heating Plate Material: Aluminum alloy with non-stick Teflon coating on die heads

Key Kit Components

• 1x Fusion Welder Unit: Equipped with an adjustable temperature control knob and dual LED status indicators (Power / Ready).

• 6x Teflon-Coated Heating Dies: Standard sizes included:

  • 20mm, 25mm, 32mm, 40mm, 50mm, and 63mm.

• 1x Floor Stand / Table Clamp Base: Provides stability during benchwork or floor operations.

• 1x Metal Carrying Case: Heavy-duty steel box for organized transport and protection on job sites.

• Included Auxiliary Tools: PPR pipe cutter, tape measure, hex key wrench, and mounting bolts.
